Part Number -

CX5500

InTemp Cellular IoT Gateway

Bluetooth connection to data loggers for cold chain cloud automation services

$499.00 USD
The CX5500 Gateway automatically downloads data from in-range InTemp CX loggers and uploads it to the InTempConnect cloud platform via a cellular connection, enabling automatic alarm notifications, compliance report automation, and remote monitoring capabilities.

Important Information

This product is only available to US customers. If you are outside of the US, please consider the CX5001 WiFi/Ethernet Gateway.

Requirements:

  • CX Gateway Annual Cellular Data Plan [(SP1-CX5500): $200 per Gateway/per year, added automatically to purchase]
  • InTempConnect cloud account, at least one CX data logger, a compatible mobile device, and InTemp mobile app (for configuration).

Contact Sales

Overview

The CX5500 Gateway works with cellular networks to seamlessly link your InTemp CX data loggers to the InTempConnect cloud platform without adding an external device to your organization’s network. (using the required cellular data plan, SP1-CX5500, which is added to your cart when purchasing.) Once the Gateway is configured via mobile device using the free InTemp Mobile App, you can place it within a 100-foot (30.5 meter) range of one or more InTemp CX loggers. The Gateway automatically downloads data at your chosen fixed intervals—twice daily, once daily, weekly, or monthly—and uploads it to InTempConnect, giving you 24/7 remote access to data, from anywhere, real-time text and/or email notifications if temperature excursions occur, and an ability to automate compliance reporting.

Included Items:

  • Mounting kit
  • AC adapter
  • Cellular antennas
  • Quick start guide

Required Items:

Features
  • Automates logger management (downloading and configuring) to reduce manual, on-site activities
  • Notifies you of temperature, humidity, and or excursion of low device battery in real time via text message and or email
  • Cellular data connectivity to upload your logger’s data directly to the InTempConnect cloud platform
  • Removes the need to add an external device to your organization’s network
  • Decreases the risk of product loss
  • Reduces time spent on regulatory compliance activities
Specifications
Transmission Range
Approximately 30.5 m (100 ft) line-of-sight
Wireless Data Standard
Bluetooth 4.2 (BLE)
Connectivity
Cellular Cat 1 LTE with 2G/3G fallback
Power Source
AC adapter
Dimensions
12.7 x 12.7 x 2.99 cm
5.0 x 5.0 x 1.18 inches
External Antennae: 3.81 x 19.58 cm
1.5 x 7.71 inches
Weight
680 g
24 oz
CE Compliance Mark
Documents

CX5500 Quick Start Guide

View View

CX5500 User Guide

View View
FAQs

Yes. Using cellular service instead of WiFi or Ethernet service, the CX5500 Gateway station can automatically download data from in-range InTemp CX loggers and upload it to the InTempConnect cloud platform. This allows you to remotely set and receive automatic alarm notifications, automate compliance reports, and more, from anywhere.
